L3-lite Managed Gigabit/10G Stackable Switch

S2900 switching series has rich selection of ports and power supplies to meet diversified network demand, first-rate hardware quality loaded with well-featured and easy-managed software

Highlight Features

Innovative Virtual Cluster Switching Technique

Industrial Ethernet Ring with Zero Delay and Zero Packet Loss

Telecom-Level Ethernet Switch

Typical Application

Technical Parameter

Gigabit Interface
RJ45 8
SFP /
10GE/GE Interface 4 SFP+
Console(RJ45) 1
Backplane(Gbps) 128
Forwarding rate (Mpps with 64 bytes) 72
Chassis
Dimensions (WxDxH)(mm) 280x180x44
Weight (KG)(empty) 1.3
Package
Dimensions (WxDxH)(mm) 350x268x94
Weight(KG) 2.3
Power consumption
no-load < 22W
full-load 35W
Power supply AC: 100V-240V DC: 36-72V 45W
Total output BTU (1000BTU/H=293W) 153.58
Fan number /
Noise@25°C(dBA) 0
MTBF(H) >200,000
Forwarding mode Store-forward
Flash (MB) 16
DRAM (MB) 256
MAC 16K
Buffer size(MB) 1.5
Interface vlan 64
Routing table 512
Jumbo frame 9K
Gigabit Interface
RJ45 2
SFP /
10GE/GE Interface 10 SFP+
Console(RJ45) 1
Backplane(Gbps) 240
Forwarding rate (Mpps with 64 bytes) 153
Chassis
Dimensions (WxDxH)(mm) 280x180x44
Weight (KG)(empty) 1.3
Package
Dimensions (WxDxH)(mm) 350x268x94
Weight(KG) 2.0
Power consumption
no-load < 14W
full-load 35W
Power supply
AC: 100V-240V DC: 36-72V 45W
Total output BTU (1000BTU/H=293W) 153.58
Fan number /
Noise@25°C(dBA) 0
MTBF(H) >200,000
Forwarding mode Store-forward
Flash (MB) 16
DRAM (MB) 512
MAC 32K
Buffer size(MB) 2
Interface vlan 1023
Routing table 12K
Jumbo frame 9K
Gigabit Interface
RJ45 /
SFP /
10GE/GE Interface 8 RJ45 + 4 SFP+
Console(RJ45) 1
Backplane(Gbps) 240
Forwarding rate (Mpps with 64 bytes) 180
Chassis
Dimensions (WxDxH)(mm) 440X280X44
Weight (KG)(empty) 3.5
Package
Dimensions (WxDxH)(mm) 576x448x94
Weight(KG) 4.5
Power consumption
no-load < 22W
full-load 35W
Power supply
AC: 100V-240V DC: 36-72V 45W
Total output BTU (1000BTU/H=293W) 153.58
Fan number 2
Noise@25°C(dBA) 0
MTBF(H) >200,000
Forwarding mode Store-forward
Flash (MB) 16
DRAM (MB) 512
MAC 32K
Buffer size(MB) 2
Interface vlan 1023
Routing table 12K
Jumbo frame 9K
Gigabit Interface
RJ45 24
SFP /
10GE/GE Interface 4 SFP+
Console(RJ45) 1
Backplane(Gbps) 128
Forwarding rate (Mpps with 64 bytes) 96
Chassis
Dimensions (WxDxH)(mm) 440x180x44
Weight(KG)(empty) 2.6
Package
Dimensions (WxDxH)(mm) 500x320x80
Weight(KG) 3.9
Power consumption
no-load <22W
full-load 35W
Power supply
AC: 100V-240V DC: 36-72V 45W
Total output BTU (1000BTU/H=293W) 153.58
Fan number /
Noise@25°C(dBA) 0
MTBF(H) > 200,000
Forwarding mode Store-forward
Flash (MB) 16
DRAM (MB) 256
MAC 16K
Buffer size(MB) 1.5
Interface vlan 64
Routing table 512
Jumbo frame 9K
Gigabit Interface
RJ45 8(Combo)
SFP 24
10GE/GE Interface 4 SFP+
Console(RJ45) 1
Backplane(Gbps) 128
Forwarding rate (Mpps with 64 bytes) 96
Chassis
Dimensions (WxDxH)(mm) 440x280x44
Weight(KG)(empty) 4
Package
Dimensions (WxDxH)(mm) 576x448x94
Weight(KG) 5.2
Power consumption
no-load < 18W
full-load < 38W
Power supply
(AC: 100V-240V, DC: 36V-72V) 45W
Total output BTU (1000BTU/H=293W) 153.58
Fan number 2
Noise@25°C(dBA) 45
MTBF(H) > 200,000
Forwarding mode Store-forward
Flash (MB) 16
DRAM (MB) 256
MAC 16K
Buffer size(MB) 1.5
Interface vlan 64
Routing table 512
Jumbo frame 9K
Gigabit Interface
RJ45 48
SFP /
10GE/GE Interface 4 SFP+
Console(RJ45) 1
Backplane(Gbps) 216
Forwarding rate (Mpps with 64 bytes) 132
Chassis
Dimensions (WxDxH)(mm) 440x280x44
Weight(KG)(empty) 4.3
Package
Dimensions (WxDxH)(mm) 576x448x94
Weight(KG) 5.5
Power consumption
no-load < 25W
full-load <48W
Power supply
(AC: 100V-240V, DC: 36V-72V) 50W
Total output BTU (1000BTU/H=293W) 163.82
Fan number 2
Noise@25°C(dBA) 45
MTBF(H) > 200,000
Forwarding mode Store-forward
Flash (MB) 16
DRAM (MB) 512
MAC 32K
Buffer size(MB) 2
Interface vlan 64
Routing table 512
Jumbo frame 9K
Gigabit Interface
RJ45 48
SFP /
10GE/GE Interface 6 SFP+
Console(RJ45) 1
Backplane(Gbps) 216
Forwarding rate (Mpps with 64 bytes) 162
Chassis
Dimensions (WxDxH)(mm) 440x280x44
Weight(KG)(empty) 4.3
Package
Dimensions (WxDxH)(mm) 576x448x94
Weight(KG) 5.5
Power consumption
no-load < 25W
full-load <48W
Power supply
(AC: 100V-240V, DC: 36V-72V) 50W
Total output BTU (1000BTU/H=293W) 163.82
Fan number 2
Noise@25°C(dBA) 45
MTBF(H) > 200,000
Forwarding mode Store-forward
Flash (MB) 16
DRAM (MB) 512
MAC 32K
Buffer size(MB) 2
Interface vlan 64
Routing table 512
Jumbo frame 9K
Gigabit Interface
RJ45 /
SFP 48
10GE/GE Interface 6 SFP+
Console(RJ45) 1
Backplane(Gbps) 216
Forwarding rate (Mpps with 64 bytes) 162
Chassis
Dimensions (WxDxH)(mm) 440x280x44
Weight (KG)(empty) 4.3
Package
Dimensions (WxDxH)(mm) 576x448x94
Weight(KG) 5.5
Power consumption
no-load < 40W
full-load < 85W
Power supply
AC: 100V-240V DC: 36-72V 150W
Total output BTU (1000BTU/H=293W) 511.49
Fan number 2
Noise@25°C(dBA) 45
MTBF(H) >200,000
Forwarding mode Store-forward
Flash (MB) 16
DRAM (MB) 512
MAC 32K
Buffer size(MB) 2
Interface vlan 64
Routing table 512
Jumbo frame 9K

Features

VLAN

4K Active VLAN, QinQ & Selective QinQ, GVRP, Private VLAN, Voice-VLAN

Spanning Tree

802.1D (STP), 802.1W (RSTP) and  802.1S (MSTP)

BPDU guard, root guard and  loopback guard

Multicast

IGMP v1/v2/v3,  IGMP Snooping,  IGMP Fast Leave, MVR, IGMP  filter

PIM-SM/SSM(2T10X/8TG4X)

IP

Static route,RIPv1/v2, OSPFv2

BGP(2T10X/8TG4X)

IPv4/v6 dual stack

IPv6

ICMPv6, DHCPv6, ACLv6 and  Ipv6 Telnet

IPv6 neighbor discovery,Path  MTU discovery

MLD V1,MLD snooping IPv6  Static Routing,RIPng, OSPFv3

Manual tunnel,ISATAP tunnel,6  to 4 tunnel(2T10X/8TG4X)

Certification

CE, FCC, ROHS

QoS

CAR, HQoS, MAC/IP/TCP/UDP/VLAN/ COS/ DSCP/ TOS based QoS, 802.1P/ DSCP priority relabeling, SP, WRR, and “SP+WRR”, Tail-Drop, WRED, flow monitoring and traffic shaping

Security

Port isolation, Port security, and “IP+MAC+port” binding, MAC sticky

DHCP Snooping and option 82,  DAI & IP source guard, PPPoE+,

IEEE 802.1x, Radius and  TACACS+

L2/L3/L4 ACL flow identification  and filtrationAnti-attack from DDoS,  TCP’s SYN Flood, UDP Flood, etc.  Broadcast/multicast/unknown  unicast storm-control

MD5, SHA-256, RSA-1024,  AES256, etc.

DHCP

DHCP server/relay/client

DHCP snooping/option82

Reliability

Static/LACP link aggregation, Interface backup

EAPS and ERPS

ISSU uninterrupted system u pgrade

BVSS, ups to 16-units per stack

VRRP

UDLD

Management

Console, Telnet, SSH v1/2, HTTP, HTTPS, SNMP v1/v2/v3, RMON

TFTP, FTP, SFTP

NTP

ZTP

SPAN, RSPAN

Dying gasp*

Environment

Operating temperature/humidity: 0 -50℃ ,10%-90% non-condensing

Storage temperature/humidity: -20 -70℃ , 5%-95% non-condensing

Accessories

Power cord, rackmount kits, console cable

Ordering Information

S2900 L3-lite series switch
S2900-8T4X 8-Port Gigabit RJ45 + 4-Port 10GE SFP+ L3-lite Stackable Managed Switch (single AC-220V power supply; fanless, 1U, standard 19-inch rack-mounted installation)
S2900-2T10X 2-Port Gigabit RJ45 + 10-Port 10GE SFP+ L3-lite Stackable Managed Switch (single AC-220V power supply; with cooling fan , 1U, standard 19-inch rack-mounted installation)
S2900-8TG4X 8-Port 10GE RJ45 + 4-Port 10GE SFP+ L3-lite Stackable Managed Switch (single AC-220V power supply; with cooling fan , 1U, standard 19-inch rack-mounted installation)
S2900-24T4X 24-Port Gigabit RJ45 + 4-Port 10G SFP+ L3-lite Stackable Managed Switch (single AC-220V power supply, fanless, 1U, 19-inch rack-mounted installation)
S2900-24S8C4X 16-Port Gigabit SFP + 8-Port RJ45/SFP Combo + 4-Port 10G SFP+ L3-lite Stackable Managed Switch (single AC-220V power supply, with cooling fan, 1U, standard 19-inch rack-mounted installation)
S2900-48T4X 48-Port Gigabit RJ45 + 4-Port 10G SFP+ L3-lite Stackable Managed Switch (single AC-220V power supply, with cooling fan, 1U, 19-inch rack mounted installation)
S2900-48T6X 48-Port Gigabit RJ45 + 6-Port 10G SFP+ L3-lite Stackable Managed Switch (single AC-220V power supply, with cooling fan, 1U, 19-inch rack mounted installation)
S2900-48S6X 48-Port Gigabit SFP + 6-Port 10G SFP+ L3-lite Stackable Managed Switch (single AC-220V power supply, with cooling fan, 1U, standard 19-inch rack-mounted installation)
